ABS Epoxy Security Biometric Fingerprint Reader , IP67 Electronic Attendance System

ABS Epoxy Security Biometric Fingerprint Reader , IP67 Electronic Attendance System

access control board

biometric fingerprint reader

Place of Origin:

China

Hàng hiệu:

RONA

Chứng nhận:

CE / ISO9001

Model Number:

RNCF-CR3

Liên hệ với chúng tôi
Yêu cầu Đặt giá
Chi tiết sản phẩm
Name::
Fingerprint time attendance
Operating Temperature:
- 20 to + 65
Colour:
Silver, Black, you can customize
Output Format::
ID/IC card
Support Card Type::
IP67
Beeper::
YES
Service::
OEM/ODM, SDK free
Material::
ABS+Epoxy
Điều khoản thanh toán và vận chuyển
Minimum Order Quantity
1
Giá bán
negotiation
Packaging Details
Carton
Thời gian giao hàng
7-15 ngày làm việc
Payment Terms
L/C, T/T,
Khả năng cung cấp
2000 chiếc mỗi tháng
Mô tả sản phẩm

ABS Epoxy Security Biometric Fingerprint Reader , IP67 Electronic Attendance System

1. Brief Introduction of Fingerprint reader

RNCF-CR3  is an ultrathin biometric fingerprint time attendance terminal, it shows fashionable and elegant. It firstly applies In-Mold Decoration technology in the market, agents/distributors could customize different front case according to yours markets, it also can satisfy diversified products based one mold, so that to differentiate different markets and realize the maximum market share.
Features of Fingerprint reader :

  • With the most advanced fingerprint arithmetic in the world, automatically analyze the tiny difference of the latest fingerprints vs. the previous fingerprints and update accordingly to ensure the high accuracy and the optimum speed of fingerprint recognition, the identification time is less than 1 second.
  • The device is built-in ID card sensor (optional for IC card), validate freely by Card, fingerprint and password combination, access control is more flexible and secure.
  • 2.8 inch TFT color screen.
  • Support U disk to download or upload attendance records and fingerprint data ect. User could enroll the fingerprint in one device, and share the enrollment information with other devices through the USB flash memory.
  • TCP/IP communication, network connection is simple and convenient, support Push Technology, operate access control networking and data collection & sharing freely
  • Supports 11 & 18 digits for user ID registration, user also could enroll mobile number for ID numbers.
  • Authentication modes are 1:1 and 1:N, user can register ten fingers, max fingerprint capacity is 1,000 enrollment and 100,000 records.
  • Support multi development language(VB, C++, C#, Delphi ect) SDK, and ODM/OEM software development.
  • Support English, Germany, Spanish ect different languages.
Product Parameter of Fingerprint reader :
Model  (RNCF-CR3 --Fingerprint time attendance)
LCD Screen2.8 inch TFT (320*240) Color Screen
Fingerprint Sensor Resolution500DPI (Optical sensor)
Hardware PlatformREALANDR ZDC2911
Algorithm VersionREALANDR RSFv5.1
CPUARM926EJ CPU, Running Frequency: 200MHZ
CommunicationTCP/IP, RS485, USB Memory Disk
User Capacity1,000
Records Capacity100,000
Software OSXP/Win2003/Vista/Win7/Win8 (32bit / 64bit)
Identification Time< 1 S
Authentication MethodFingerprint/ RFID Card (125Khz, EM4100)
LanguageChinese / English / Spanish/Portuguese/ German (could customize others)
BellBuilt-in timing bell
PowerDC 5V/1A
FRR<1%
FAR<0.00001%
Operating ModeOff-line/On-line
Authentication Mode1:1, 1:N
Operating environmentOperating Temp: 0°C-50°C, Humidity: 80%
CertificatesCE, Type Inspection Report of Chinese Police Product


ABS Epoxy Security Biometric Fingerprint Reader , IP67 Electronic Attendance System 0


ABS Epoxy Security Biometric Fingerprint Reader , IP67 Electronic Attendance System 1

ABS Epoxy Security Biometric Fingerprint Reader , IP67 Electronic Attendance System 2
